Description
| Technical Specifications | |
|---|---|
| Power supply | AC 100V – 240V |
| Power consumption | Normal operation 5 W |
| Network protocols | Art-Net protocols & Seekway protocols |
| Data output | SPI TTL / DMX RS-485 / SW MCU / Breakpoint resume Art-Net protocols: SPI chip: 4 universes × 512 channels × 8 ports Standard DMX512: 2 universes × 512 channels × 8 ports Seekway protocols: SW MCU: 2880 channels ×8 ports SPI chip: 3072 channels ×8 ports Standard DMX512: 512 channels ×8 ports Extensible DMX: 1024 channels ×8 ports Break-point resume: 2160 channels ×8 ports 65536 gray scale: 2160 channels×8 ports |
| Supported LED models | SW MCU: D**S, D**J. SPI: TM180*-400K/800K, UCS19**, UCS29**, WS2811/12, TLS3001(1Mhz), SM167**. DMX512: SW-D, SW-U, UCS512A/B/C0/C4/D/E0/EH/G4/G6, DMX512AP/SM512, SM16500P/511/512, SM17500P/512P/522P, SM17512/522, SM18522P/PH, SM16823E/824E, Hi512A0/A4/A6, TM512AB3/AL1/ACx/AD/AE, QED512P, GS8512/513/515, standard DMX512 lighting fixture on the market. Please refer to the “”CHIP SUPPORT”” section for addressing. Break-point resume: UCS5603, WS2818, GS8206, P9883, TM1914, XT1506S. 65536 Gray scale: UCS8903, UCS8904, UCS9812, SM16813.” |
| Port | 8 ports (5P Terminal Block × 9, Contains a spare) |
| Ethernet | 2 x RJ45 |
| Transmission distance | Category 5e unshielded network cable, 100 meters between controllers. For longer distances, “fiber converter” can be used, up to 5 kilometers. |
| Shell material | Iron |
| Operate | 4 buttons + 2 network status indicators |
| Size | 285 mm ×156 mm × 45 mm (11.23 in× 6.14 in. × 1.77 in.) (L×W×H) |
| Temperature range | -10 degrees Celsius to 70 degrees Celsius (14 degrees Fahrenheit to 158 degrees Fahrenheit) |
| Relative humidity | 5 % to 50 %, non-condensing |
| IP rating | IP20 |
| Warranty | The manufacturer offers a 2-year limited warranty |
